DESCRIPTION

Overview

Basic Info.

Model NO.	HTDFMT
Sample	Free
Lead Time	7-14 Days
Application	Hand Lay up FRP Products/Boat /Car
Roll Weight	10kg, 30kg, 40kg, 55kg
Binder Type	Emulsion Binder, Powder Binder
Roll Width	4inch - 50inch / 10cm - 300cm
Standard Density	225GSM/300GSM/450GSM/600GSM
Transport Package	Carton + Pallet
Specification	80-900 gsm
Trademark	HONTED
Origin	China
HS Code	7019390000
Production Capacity	1800 Tons/Month

Product Description

Product Description

→Fiberglass Chopped Strand Mat is an non-woven E- or C-glass fiberglass fabric manufactured by spreading continuous filament rovings of 50mm in length randomly and uniformly in combination with polyester binder in power form (or other binder in emulsion form).Chopped Strand Mat (CSM) is a random fiber mat that provides equal strength in all directions and is used in a variety of hand lay-up and open-mold applications. Chopped strand mat is produced by chopping continuous strand roving into short 1.5 to 3 inch lengths and dispersing the cut fibers randomly over a moving belt to from a "sheet" of random fiber mat. A binder is applied to hold the fibers together and the mat is trimmed and rolled. Because of is random fiber orientation, chopped strand mat conforms easily to complex shapes when wet-out with polyester or vinyl ester resins. Chopped strand mats are available as a roll stock product produced in a variety of weights and widths to suite specific applications.

Fiberglass mat (also known as chopped strand mat) has strands of fiber that are randomly oriented and held together with a styrene binder. When a resin is added to the mat, the binder dissolves and the fibers can be moved around.Chopped strand mat is very strong due to the fiberglass fibers compressed together at random angles, can be used for Matched Metal Die wet molding, Open mold applications. Chopped Strand Mat is used to build up thickness quickly and is often layered in between fiberglass fabric. It is compatible with polyester and vinyl ester resin.
Mat Production ProcessAssembled rovings are chopped to a specified length, and then fall onto a conveyor randomly. The chopped strands are bonded together by either an emulsion binder or a powder binder. After drying, cooling and winding, a chopped strand mat is formed.

Emulsion Chopped Strand MatEmulsion Chopped Strand Mats are made of randomly distributed chopped strands held together by an emulsion binder. They are compatible with UP and VE resins. The roll width ranges from 200mm to 3,120mm. Special requirements may be available upon request.Powder Chopped Strand MatPowder Chopped Strand Mats are made of randomly distributed chopped strands held together by a powder binder. They are compatible with UP, VE, EP and PF resins. The roll width ranges from 200mm to 3,120mm. Additional demands on wet-out and decomposition time can be available upon request.Product Features

1.Even tickness moderated rigidness.2.Easy wet out and impregnation.3.Filament have outstanding anti-wash ability and easy wet out and impregnationg excellent process ability in moulded parts,applying for diversity moulding and processing.4.Specially in opened moulding and closed moulding.5.Excellent mechanical strength during production of finished product.

Product Parameters

Item	EMC180	EMC225	EMC300	EMC450	EMC600
Weight per unit area ( g/m2 )	180	2225	300	450	600
Weight average value tolerance rate (%)	±10	±10	±10	±10	±10
Loss on ignition ( % )	2~ 8	2~8	2~ 8	2~8	2~8
Moisture content ( % )	< 0.20(powder)<0.50(emulsion)	<0.20(powder)<0.50(emulsion)	<0.20(powder)< 0.50(emulsion)	<0.20(powder)< 0.50(emulsion)	<0.20(powder)< 0.50(emulsion)
Breaking strength (N/150mm)	≥ 40	≥ 40	≥ 60	≥ 60	≥ 80

Density: 0.75 oz / sq.ft chopped strand mat 1.5 oz / sq.ft chopped strand mat 2.0 oz / sq.ft chopped strand mat 3.0 oz / sq.ft chopped strand matWidth: 4 inch, 6 inch, 38inch and 50 inch wide or as customers' requirement.

Packaging & Shipping

Related Products

Woven Roving Stitched Mat WR Combo Mat Surface Tissue Fiberglass Cloth Multiaxial Fabric Mat

Storage

Unless otherwise specified, the fiberglass products should be in dry, cool and moisture-proof area. The room temperature and humidity should be always maintained at 15ºC~35ºC and 35%~65%. It is best if the product is used within 12 months after production date. The fiberglass products should remain in their original packaging until just prior to user.

Application

Fiberglass mat is compatible with unsaturated polyester, vinyl ester, epoxy and phenolic resins. It is designed for use in hand lay-up, filament winding, compression molding and continuous laminating processes. Its end-use applications include boats, bath equipment, automotive parts, chemical corrosion resistant pipes, tanks, cooling towers and building components.

FAQs

1. What is your terms of packing?
Generally, we pack our goods in carton with pallet
2. What is your tems of payment?
T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.3. What is your terms of delivery?
EXW, FOB, CFR, CIF,L/C at sight4. How about your delivery time?
Generally, it will take 21 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.5. Can you produce according to the samples? Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
6. What is your sample policy?
We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.

7. Do you test all your good before delivery? Yes, we have 100% test before delivery
